HS
High Flow Rate Single Cartridge Filter Housing ( High Pressure)

Design P. 15kg/cm²     Operating P. 10kg/cm²
Design T. 100˚C           Operating T. 75˚C

Material：SUS304 SUS316
O-ring   ：EPDM/VITON/NBR/SILICONE/TEFLON+VITON
Surface finished：Acid-Washing,Electrolyze and Other unique surface finished.

Features

●High flow design could satsify customers needs
●High flow housing designed for smaller shell body, reducing the installation cost and saving the site space
●High flow housing designed for horizontal installation can easy for cartridge replacement

Applications

●Water
●Groundwater
●Food Industry
●Beverage Industry
●Environmental Industries
●Electronic Industry
●Machinery oil
●Electroplating Industry
●Petrochemical Industry
●Pool
●Unique liquid filtration
●Industrial wastewater treatment

Specifications
I m/m
H m/m
Model
Length of Cartridge
A m/m
B m/m
C m/m
D m/m
E m/m
F m/m
G m/m
200
160
HS
40"
Ø232
1230
125
65
1050
176
300
200
160
HS
60”
Ø216
1740
125
65
1560
168
300
Purchase Code
HS
4
4
50
10K
E
1
2
Product code Length of Cartridge Material In&Outlet size In&Outlet type O-ring Material Interior surface finished Exterior surface finished


4-40"
6-60" 		4-304
6-316
 15-1/2"
20-3/4"
25-1"
40-1-1/2"
50-2"
65-2-1/2"
80-3" 		10K-JIS
150P-ANSI
PN10-DIN
J-Clamp
PF-BSPT-F
BF-BSPF-F
NF-NPT-F
 E-EPDM
V-Viton
N-NBR
S-Silicone
TV-Teflon+Viton 		1-Acid-Washing
 1-Acid-Washing
2-Electrolyze
3-Polishing
