Design P. 20kg/cm² Operating P. 14kg/cm²
Design T. 70˚C Operating T. 40˚C
Material：SUS304 SUS316
Head Material： SUS304 SUS316
Clamp Type：One piece type by Precision casting
Surface finished：Polishing,Electrolyze and Other unique surface finished.
●Using two clamps to fix two sides of head, easy to install and easy to clean.
●Made by MIT SS304, SS316 material, suitable for various industry and food grade industry filtration.
●High flow capacity , high capacity.
●Shell strength calculation according to CNS standard.
●Using electrolyze for surface finished, no stain stick on the shell.
●Bottom cover and shell was sealed very tight, in order to prevnt RO from leaking.
●High strength metallic materials, solid structure, to extend the usage of RO.
●Water
●Groundwater
●Food Industry
●Beverage Industry
●Environmental Industries
●Electronic Industry
●Machinery oil
●Electroplating Industry
●Petrochemical Industry
●Pool
●Unique liquid filtration
●Industrial wastewater treatment
 |
|
|
RO80
|
40
|
4
|
25
|
PF
|
40
|
V
|
E
|
1
|
5
|
| Product code | Length of Shell | Material | N1 Size | N1 Type | N2 Size | N2 Type | O-ring Material | Interior surface finished | Exterior surface finished |
| 40 80 120 160 200 |
4-304 6-316 |
PF-BSPT-F NF-NPT-F V-Mechanical connector J-Clamp |
PF-BSPT-F NF-NPT-F V-Mechanical connector J-Clamp |
E-EPDM |
5-Burnishing |
|
Detail
|
Weight
|
Length
|
Width
|
Height
|
Carton
|
|
RO8040
|
31
|
1350
|
310
|
310
|
YES
|
|
RO8080
|
47
|
2430
|
310
|
310
|
YES
|
|
RO80120
|
63
|
N/A
|
|||
|
RO80160
|
78
|
N/A
|
|||
|
RO80200
|
94
|
N/A
|
